ProSecure Unified Threat Management (UTM) Appliance Reference Manual
System Logs and Error Messages C-5
v1.0, January 2010
WAN Status
This section describes the logs that are generated by the WAN component. If there are two ISP
links for Internet connectivity, the router can be configured either in auto-rollover mode or load
balancing mode.
Auto-Rollover Mode
When the WAN mode is configured for auto-rollover, the primary link is active and secondary acts
only as a backup. When the primary link goes down, the secondary link becomes active only until
the primary link comes back up.
The device monitors the status of the primary link using the configured WAN Failure Detection
method.
This section describes the logs that are generated when the WAN mode is set to auto-rollover.
System Logs: WAN Status, Auto Rollover
Message Nov 17 09:59:09 [UTM] [wand] [LBFO] WAN1 Test Failed 1 of 3 times_
Nov 17 09:59:39 [UTM] [wand] [LBFO] WAN1 Test Failed 2 of 3 times_
Nov 17 10:00:09 [UTM] [wand] [LBFO] WAN1 Test Failed 3 of 3 times_
Nov 17 10:01:01 [UTM] [wand] [LBFO] WAN1 Test Failed 4 of 3 times_
Nov 17 10:01:35 [UTM] [wand] [LBFO] WAN1 Test Failed 5 of 3 times_
Nov 17 10:01:35 [UTM] [wand] [LBFO] WAN1(DOWN), WAN2(UP),
ACTIVE(WAN2)_
Nov 17 10:02:25 [UTM] [wand] [LBFO] WAN1 Test Failed 6 of 3 times_
Nov 17 10:02:25 [UTM] [wand] [LBFO] Restarting WAN1_
Nov 17 10:02:57 [UTM] [wand] [LBFO] WAN1 Test Failed 7 of 3 times_
Nov 17 10:03:27 [UTM] [wand] [LBFO] WAN1 Test Failed 8 of 3 times_
Nov 17 10:03:57 [UTM] [wand] [LBFO] WAN1 Test Failed 9 of 3 times_
Nov 17 10:03:57 [UTM] [wand] [LBFO] Restarting WAN1_
